Description
IDS-322 is an innovative secure 2 port RS-232/422/485 to 2 ports LAN secure device server with standard features of device server, such like TCP/IP interface and versatile operation modes: Virtual Com, Serial Tunnel, TCP Server, TCP Client, and UDP. In addition, the Windows untility, DS-Tool, could configure multiple devices and set up the mappings of Virtual Com. On the other hand, IDS-322 can simultaneously transfer data up to 5 redundant host PCs to aovid Ethernet connection breakdown or any host PC fails. Further, IDS-322 features HTTPS, SSH, and SSL encryption to assure the security of critical data transmission.
IDS-322 supports RS-232/422/485 and provides dual redundant power inputs, 12~48 VDC, on terminal block to guarantee a non-stop operation. Further, IDS-322+ features PoE PD (Power Device) function, compliant with IEEE802.3af standard, with 1kv isolation on the PoE port. With wide operating temperature, -40~70°C, and rugged IP-30 housing design, IDS-322 series could operate in the harsh industrial environment. Therefore, IDS-322 is the best solution to the high demand of secure serial to Ethernet critical data communication.
Features
-
Operating Modes: Virtual Com, Serial Tunnel, TCP Server, TCP Client, UDP
-
Support 2xRS-232/422/485 in DB9 connector
-
Redundant multiple host devices: 5 host devices: Virtual COM, TCP Server, TCP Client mode;4 IP ranges: UDP
-
Security: SSL data encryption; secured management by HTTPS and SSH:IP Access: IP White List
-
Event Warning by Syslog, Email, SNMP trap, Relay and Beeper
-
Configurable by Web-based and Windows utility (DS-Tool)
-
Various Windows O.S. supported: Windows NT/2000/ XP/ 2003/VISTA(32/64bit)/ Windows 7(32/64bit)
-
Ethernet switch mode enable Daisy Chain
